10/100/1000M Media Converter
10/100/1000M Media Converter
10/100/1000Media Converter is 10/100/1000Mbps fast Ethernet converter. The converter mediates between a 100/1000Base-TX segment and a 1000Base-FX segment. It is primarily designed for large, higher speed/bandwidth demanding work groups that require expansion of the Ethernet network. It can extend the conventional 10M Ethernet or 100/1000M Fast Ethernet to 20Km-120Km via the fast Ethernet Fiber-optical Line. It is high performance, cost effective and flexible solutions for a wide range of applications in the field of LAN campus network.onnectors and RJ-45 connector.
FEATURES:
Provide one fiber connector and one UTP connector
Fully complies with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.2ab 1000Base-TX, IEEE802.3z 1000Base-FX standard
Auto-detection of half/full duplex transfer mode for TX port
Auto-negotiation of 10/100/1000Mbpa rate and Auto-MDI/MDIX for TX port
Provide switch configuration of half/full duplex transfer mode for FX port
Extend fiber distance up to 2km for multi-mode fiber and 20-120km for single-mode fiber
Compacts size for easy installation and working with Media Chassis
Choice of fiber-connector from SC, LC and WDM, multi-mode / single-mode fiber for 1000Base SFP interface
Easy-to-view LED indicators provides status to easily monitor network activity Internal power supply
1000Base-SX: 50/125ìm or 62.5/125ìm multi-mode fiber cable, up to 220/550m
1000Base-T: 2-pair Cat. 5/5e/6 UTP cable, up to 100 meters
Back pressure flow control for full duplex IEEE802.3 X and half duplex.
APPLICATION:
