Mini PLC 1x8

SC/APC 0.9mm 1X8 Fiber Optic PLC Splitter Steel Tube Package PLC Splitter is Based on the Planar Waveguide Technology. It Provides a Low Cost Power Distribution Solution with Small Form Factor and High Reliability, wide operating wavelength range and good channel-to channel uniformity, and is widely used in PON net.

Item Model: Mini PLC 1x8

FOB Port: NINGBO

MOQ: 50PCS

Lead Time: 10DAYS

Contact

Description

Module Fiber Splitter PLC Firstfiber SC/APC POS Mini 1x8 FF Passive 900um

Features:
Excellent Mechanical,Small Size
High Reliability
Low insertion Loss and low Polarization Dependent loss
High channel counts
Excellent Environmental Stability and Widely Used
Applications:
FTTx Deployments(GPON/BPON/EPON)
Cable television (CATV)
Local area networks (LAN)
Test equipment
Passive optical networks(PON)

specification
(Number of Channels)	1×2	1×4	1×8	1×16	1×32	2×8	2×16
Operating Wavelenth	1260 to 1650
P Level Insertion Loss	4	7.4	10.5	13.7	17	10.8	14.1
S Level Insertion Loss	4.2	7.6	10.7	14	17.3	11.2	15
Uniformity	0.4	0.6	0.8	1	1.2	1.2	1.4
PDL	0.2	0.3	0.3	0.3	0.5	0.3	0.3
Return Loss	more than 55
Directivity	more than 55
Type of fiber	ITU G657A
Operating temperature	-40 to 85
Pigtail length	1m or 1.5m or customized
